Introduction to Python programming

1. Activity Identity

2. Learning Objectives and Competences

3. Prerequisites

• Basic knowledge of computers and programming concepts (variables, loops, functions)

• Basic knowledge of command line interface (terminal) and file management

• Safety rules for powered electronics

• Ability to capture evidence: screenshots, logs or observation tables

4. Required Material and Setup

5. Safety, Ethics and Accessibility Notes

Battery and wiring safety must be checked before powering the robot.

Make sure there is enough space around the robot to move safely, and that there are no obstacles that could cause damage to the robot or the environment.

Visual Accessibility: IDEs like VS Code and PyCharm support high-contrast themes and font scaling. Students are encouraged to adjust the terminal and editor font sizes using Ctrl + ‘+’ for better readability if needed.

6. Scenario and Problem Statement

Python is one of the most popular programming languages in AI, robotics, and many other fields. In this lab, you will learn the basics of Python programming and how to use it to control a robot. This instruction will cover Python syntax, data structures, and basic programming concepts. However, if you want to learn more about Python, there are many online courses and tutorials (e.g., Harvard CS50’s Introduction to Python or w3schools Python tutorial) that can help you deepen your knowledge.

7. Lab Workflow

8. Step-by-Step Instructions

Step 0 - Initial environment preparation [skip if using the workstations in the laboratory]

1. Install Python using the following commands in terminal:

Update the package list:

sudo apt update

Install the recommended Python3 version for your operating system, with pip (Python package manager) and venv (virtual environment) support:

sudo apt install python3 python3-pip python3-venv

You can check the installed Python version with:

python3 --version

2. Install an IDE of your choice (e.g., Visual Studio Code or PyCharm) and set it up for Python development.

   • for Visual Studio Code, you can use the following command:

    sudo snap install --classic code

   and then install the Python extension from the marketplace. To open the current folder in VS Code, use: bash code .

   • for PyCharm, you can use the following command:

   sudo snap install pycharm-community --classic

   Then, open PyCharm and create a new project, selecting the Python interpreter you installed in step 1.

Step 1 - Environment preparation

1. In case the students before haven’t removed the directory related to this instruction, you should remove it:

rm -rf fossbot-python-lab

2. Create a new directory for this project and navigate into it:

mkdir fossbot-python-lab
cd fossbot-python-lab

3. Create a new Python virtual environment for this project:

python3 -m venv fossbot-env

4. Activate the virtual environment (this ensures that any Python packages you install will be isolated to this project):

source fossbot-env/bin/activate

Expected result:: - A new directory named fossbot-python-lab is created and you are inside it. - A new virtual environment named fossbot-env is created and activated. - Your terminal prompt should now indicate that you are in the fossbot-env virtual environment (e.g., it may show (fossbot-env) at the beginning of the prompt).

Step 2 - Basics of Python programming

Below are the basic information about Python syntax and programming concepts. Please read through the following section. Because Python is a script-based language, the code is executed line by line, and it is not compiled like in C++ or Java.

1. Indentation: Python uses indentation to define code blocks. For example, a function definition looks like this:

def my_function():
    print("Hello, World!")

the code inside the function is indented, and this indicates that it belongs to the function.

Note: In Python, it is important to use consistent indentation (e.g., 4 spaces) to avoid syntax errors.

⚠️ Examples of wrong indentation:

# No indentation - this will cause a syntax error
def my_function():
print("Hello, World!")

# Inconsistent indentation - this will also cause a syntax error
def my_function():
    print("Hello, World!")
  print("This line has different indentation")

2. Variables and data types: In Python, you can store values in variables. Because Python is dynamically typed, you don’t need to declare the type of a variable (opposite to statically typed languages like C++ or Java). For example:

x = 10             # An integer
y = 2.718          # A float
name = "FOSSBot"   # A string
is_a_robot = True  # A boolean

Also you can overwrite the value of a variable with a different type:

x = 10                 # x is an integer
x = "Hello, FOSSBot!"  # x is now a string

Basic algebraic operations that you can perform:

a = 5
b = 3
sum_result = a + b       # Addition (8)
diff_result = a - b      # Subtraction (2)
prod_result = a * b      # Multiplication (15)
quot_result = a / b      # Division (1.666...)
mod_result = a % b       # Modulo (2)
pow_result = a ** b      # Exponentiation (125)
div_result = a // b      # Floor division (1)

And you can also use the operations with variables of different types:

x = 10                 # x is an integer
y = 2.718              # y is a float
result = x * y         # result is a float (27.18)

3. Data structures: To store multiple values, you can use data structures like lists, tuples, and dictionaries:

# A list is an ordered collection of items
my_list = [1, 2, 3, 4, 5]

# A tuple is an ordered, immutable collection of items
# (you cannot change the values in a tuple after it is created)
my_tuple = (1, 2, 3, 4, 5)

# A dictionary is a collection of key-value pairs
my_dict = {"name": "FOSSBot", "type": "robot", "number_of_wheels": 2}

To access the values in the abovementioned data structures, you can use indexing (for lists and tuples) or keys (for dictionaries):

print(my_list[0])       # Output: 1
print(my_tuple[1])      # Output: 2
print(my_dict["name"])  # Output: FOSSBot

To add new items to a list, you can use the append() method:

my_list.append(6)       # my_list is now [1, 2, 3, 4, 5, 6]

And to add a new key-value pair to a dictionary, you can simply assign a value to a new key:

my_dict["color"] = "blue"
# my_dict is now:
# {"name": "FOSSBot", "type": "robot", "number_of_wheels": 2, "color": "blue"}

4. Conditional statements: You can use if, elif, and else statements to perform different actions:

distance_to_target = 10

if distance_to_target > 50:
    print("The robot is far away. Get closer!")
elif distance_to_target < 5:
    print("The robot is close. Stop!")
else:
    print("The robot is at a moderate distance. Keep going!")

You can also use logical operators (and, or, not) to combine conditions:

is_obstacle_detected = True
is_battery_low = False

if not is_obstacle_detected and not is_battery_low:
    print("The robot can move forward.")
elif is_battery_low:
    print("The robot should recharge.")
else:
    print("The robot should avoid the obstacle.")

5. Loops: You can use for and while loops to repeat actions:

# A while loop is executed as long as a condition is true
i = 0
while i < 5:
    print(f"Counter: {i}")
    i += 1  # This is equivalent to i = i + 1

# A for loop iterates over some sequence (like a list or a range of numbers)
for i in range(5):  # This will iterate over the numbers 0, 1, 2, 3, 4
    print(f"Counter: {i}")

fossbot_colors = ["blue", "red", "green"]
for color in fossbot_colors:  # This will iterate over the items in the list
    print(f"Color: {color}")

Note: The range() function generates a sequence of numbers. It can take one, two, or three arguments: range(stop), range(start, stop), or range(start, stop, step). For example, range(5) generates the numbers 0 to 4, while range(1, 6) generates the numbers 1 to 5, and range(1, 10, 3) generates the numbers 1, 4, 7.

6. Functions: If you have a part of code that you want to reuse multiple times, you can define a function, so it can be called whenever needed:

def greet(name):
    print(f"Hello, {name}!")

greet("FOSSBot")  # Output: Hello, FOSSBot!

Note: The f before the string in the print() function allows you to use f-strings, which are a convenient way to format strings with variables. But you can also concatenate strings using the + operator:

def greet(name):
    print("Hello, " + name + "!")

greet("FOSSBot")  # Output: Hello, FOSSBot!

You can also return values from a function using the return statement:

def add(a, b):
    return a + b

result = add(5, 3)  # result is 8

Moreover, you can set default values for function parameters. This means that if you don’t provide a value for that parameter, it will use the default value:

def greet(name, number_of_greetings=1):
    for i in range(number_of_greetings):
        print(f"Hello, {name}!")

greet("FOSSBot")
# Output: Hello, FOSSBot!

greet("FOSSBot", 3)
# Output:
# Hello, FOSSBot!
# Hello, FOSSBot!
# Hello, FOSSBot!

Note: You can also set the variable types in the function definition, which can help with code readability and debugging, but is optional in Python:

def greet(name: str, number_of_greetings: int = 1) -> None:
    for i in range(number_of_greetings):
        print(f"Hello, {name}!")

The -> None indicates that this function does not return any value. If the function were to return a value, you would replace None with the type of the returned value (e.g., -> str if it returns a string).

7. Saving and loading data from files: You can use the built-in open() function to read from and write to files:

# Writing to a file
with open("output.txt", "w") as file:
    file.write("Hello, FOSSBot!\n")

# If you want to write multiple lines, you can use a list of strings and the writelines() method:
lines = ["Line 1\n", "Line 2\n", "Line 3\n"]
with open("output.txt", "w") as file:
    file.writelines(lines)

#If you don't want to overwrite the existing content of the file, you can open it in append mode:
with open("output.txt", "a") as file:
    file.write("This line will be added to the end of the file.\n")

Note: The \n at the end of the string indicates a new line.

# Reading from a file
with open("output.txt", "r") as file:
    data_from_file = file.read()

8. Importing libraries: To use additional functionalities, you can import libraries. There are many libraries available for Python that can help you with various tasks, such as machine learning, robot control and more. For example, to use the popular NumPy library that provides support for multidimensional arrays and mathematical functions, you can install it using pip and then import it in your code:

pip install numpy

If you need a specific version of the library, you can set install it like this:

pip install numpy==1.21.0

Then, in your Python code, you can import the library:

import numpy

some_array = numpy.array([1, 2, 3, 4, 5])
mean_value = numpy.mean(some_array)

Or you can import it with an alias for easier use:

import numpy as np

some_array = np.array([1, 2, 3, 4, 5])
mean_value = np.mean(some_array)

It is also possible to import only specific functions or classes from a library:

from numpy import array, mean

some_array = array([1, 2, 3, 4, 5])
mean_value = mean(some_array)

Step 3 - Tasks: Write scripts

In this part, you will write some basic Python scripts to practice the concepts you have learned. Inside the fossbot-python-lab directory, create a new file for each task (e.g., task1.py, task2.py) and open them in your IDE. Use the following code snippet as a template for your scripts:

def main():
    # Your code here
    pass  # This is a placeholder that does nothing. Remove it when you add your code.

# This ensures that the main() function is called when you run the script
if __name__ == "__main__":
    main()

1. Generate an array of 100 random integers between 1 and 100. Save the array to a text file, with one item per line. You can use the random module for this and the randrange() function. Check the documentation for more information https://docs.python.org/3/library/random.html. Then, calculate and print the mean of the numbers in the array. Do this using 2 approaches:

• Using a for loop and dividing the sum by the number of elements (you can use the len() method to get the number of elements in the array).
• Using the np.mean() function from the NumPy library.

Print the results in the console.

2. Load the text file from task 1. Find the most common number in the file and how many times it appears. Print the result in the console.

3. Generate an array of integers from 1 to 100 using the range() function. Do the following operations on the array:

• if the number is divisible by 3, replace it with the string “Bot”,
• if the number is divisible by 4, replace it with the string “FOSS”,
• if the number is divisible by both 3 and 4, replace it with the string “FOSSBot”.

Print the resulting array. This task is based on the classic FizzBuzz problem (e.g., https://leetcode.com/problems/fizz-buzz/description/)

4. Prepare a script that will take two inputs from user (use the input() function - documentation) - a string to encrypt and a shift value. Add validation to ensure the shift value is an integer. Write a function that will implement the Caesar cipher to encrypt the input string. Read more about the Caesar cipher here: https://en.wikipedia.org/wiki/Caesar_cipher.

5. Prepare a script that will take an integer input from user. Then, write a function that will calculate the Digital Root of the input number. The Digital Root is the recursive sum of all the digits in a number until it becomes a single digit. For example, the Digital Root of 23 is 5 (2 + 3 = 5), and the Digital Root of 999 is 9 (9 + 9 + 9 = 27, then 2 + 7 = 9). Read more about Digital Root here: https://en.wikipedia.org/wiki/Digital_root. Use a generator to implement the solution with the yield keyword to generate each digit (more about generators: https://wiki.python.org/moin/Generators).

Expected result: You should have 5 Python scripts that implement the tasks described above.

Step 4 - How to use Python for robot control

TODO: Add instructions on how to use Python to control the robot

Expected result: Scripts that can control the robot using Python.

9. Analysis Questions

1. What are the advantages and disadvantages of using Python for robotics programming compared to other programming languages (e.g., C++ or languages for specific robots)?

2. In Step 3, you saved and loaded generated data to a text file. Why is file I/O (Input/Output) an important skill when working with robot sensors? Give a practical example of how you might use this during a robotics experiment.

3. What errors did you encounter while writing the scripts, and how did you debug them? Describe one specific error and what you learned from it.

10. Submission Requirements

• Completed source code from Steps 3 and 4

• Short answer to analysis questions

• Optional: video of the final behaviour of the robot

11. References and Open Licence

• Python3 documentation: https://docs.python.org/3/
• NumPy documentation: https://numpy.org/doc/
• FOSSBotEduSim repository: https://github.com/LRMPUT/FOSSBotEduSim
• Harvard CS50’s Introduction to Python
• A tutorial on Python basics from PUT (in Polish): https://put-jug.github.io/lab-niodsr/Lab%2003%20-%20Python%20-%20podstawy.html

The Creative Commons Attribution 4.0 International (CC BY 4.0) license allows users to share, copy, distribute, and adapt the work, even for commercial purposes, as long as proper credit is given to the original creator.
